  •  Kcosit RTK17X GNSS RTK Surveying Android Tablets PC RTK 10.1 Inch High Precision GPS

Kcosit RTK17X GNSS RTK Surveying Android Tablets PC RTK 10.1 Inch High Precision GPS

stars, based on 0reviews
Price:
$499.80 / piece
Bundle
  • Standard Version
optional functions
  • 8GB RAM 128GB ROM
  • ADD UM960 Module
  • ADD F9P Module
Quantity: - + 1000items available
Contact Us

Item specifics

Brand Name:
Kcosit
Model:
RTK17X
Product Type:
Android tablet
Scanning Light Source:
Scan Element Type:
Scan Speed:
Products Status:
Stock
Operating System:
Android 12
Processor Manufacture:
MT6789  octa-core, 2*A76 2.2GHz
Screen Size:
10.1
Display resolution:
1200*1920
Touch Screen Type:
Capacitive Screen
RAM:
8 GB RAM
ROM:
128 GB
Cell Capacity:
10000mAH
Cellular:
GSM/WCDMA/ 4G LTE
Tags:
GNSS RTK Surveying Android Tablets,Rugged Tablet PC, Rugged Devices, Rugged Tablets, Industrial Tablet, Waterproof Tablet, IP 67 Waterproof Tablet, Ultra-Rugged Tablet PC, Rugged tablet With barcode scanner, Rugged Device Manufacturer,,Sunshine Readable,Rugged tablet,IP67 Waterproof,GNSS RTK,USB 3.0
Kcosit Rugged Devices --->Email: sales@kcosit.com

The RTK17X GNSS RTK Surveying Android Tablet is your ideal tool for precise geographic surveying and GIS data collection. This high-performance tablet combines a rugged design with high-precision GNSS positioning capabilities, making it perfect for professional surveyors who require accuracy and reliability. Whether for construction surveys, agricultural mapping, or geological exploration, the RTK17X delivers exceptional performance and precise location data.

Equipped with advanced RTK technology, the RTK17X supports multiple satellite navigation systems including GPS, GLONASS, Galileo, and BeiDou, providing real-time centimeter-level positioning accuracy. Powered by an MTK octa-core processor and Android 12.0 operating system, the RTK17X ensures smooth operation and powerful multitasking capabilities. Its 10.1-inch high-definition touchscreen remains clear and readable even in bright sunlight, making it ideal for outdoor use.

The RTK17X also features an 10000mAh high-capacity battery, ensuring extended outdoor operation to continuously support your surveying work. With its IP67 waterproof and dustproof rating, as well as its drop and shock resistance, the RTK17X is reliable and durable in various harsh environments. Additionally, the RTK17X supports 4G LTE, Wi-Fi, and Bluetooth 5.0, ensuring real-time data transmission and communication.

Choosing the RTK17X GNSS RTK Surveying Android Tablet means you’ll have a professional surveying device that meets demanding work requirements while offering exceptional performance and high-precision positioning. In any application scenario, the RTK17X will be your reliable partner, helping you complete your surveying tasks with ease.


  • Standard Version ( Android 12.0  )
    • Waterproof Grade:  IP65 Waterproof Level Shockproof and Dustproof

    • Operation SystemAndroid 12.0  OS

    • CPU: MT6789 2*A76 2.2GHz,6*A55 2.0GHz

    • DisplaySize: 10.1 "

    • Display Resolution: 1920X1200 Pixel  IPS    Brightness: 700cd/㎡

    • RAM+ROM: 8GB RAM+128GB ROM

    • Camera: Front: 5.0MP    Rear: 13MP auto-facus with flashlight

    • Battery Capacity: 10000mAH

    • Built-in: 3G,4G,Wifi ,GPS Module, Bluetooth Module

    • Sim Card Quantity: Single SIM Card
      NFC Reader:
      Support ISO/IEC 14443A/14443B/15693/18092/mifare protocol, reading distance: 0-4cm

    • 2G GSM(B1/B2/B5/B8)
      3G WCDMA(B1/B2/B5/B8)  TD-S(B34/B39)
      4G TDD(B38/B39/B40/B41)FDD(B1/B2/B3/B4/B5/B7/B8/B17/B 20)

    There are two Precision GNSS RTK Module Optional

    1.  Ublox  ZED-F9P Module
    2.  Unicorecomm UM960 Module

    Standard Package Include: (standard without Charger Docking)

    1. 1X Tablet
    2. 1X Battery 10000mAh (Removable)

    3. 1X Type-C  Charger (US or EU )

    Product Form10.1 inch  Rugged Tablet
    MaterialPC+10%GF+TPU
    Dimension274.9*188.7*23.1mm (GNSS antenna: Diameter 27.5mm, length 113mm)
    WeightTBD
    Product ColorBlack
    CPUMT6789  octa-core, 2*A76 2.2GHz
    GPUARM G57 MC2
    Memory StorageRAM 8GB  LPDDR4                    ROM  128GB Emmc
    Operating SystemAndroid 12 / GMS
    DisplayType: TFT Size: 10.1 inch   16:10  Resolution:  1200*1920 Brightness: 700cd/㎡
    Touch Pannel10 points capacitive screen, G+G, hardness 7H
    CameraFront 5.0MP   Rear 13.0MP, with  flashlight
    ButtonsPower *1,Volume Adjustment Key (+) *1,Volume Adjustment Key (-) *1
    F Customizable *1 (Barcode Scanning),Home Key*1
    IndicatorIndicator lights * 2, R/G dual-color lights.
    1. During charging, they will be constantly red.
    2. When fully charged, they will display a constant green light.
    3. When the battery is low, the red light will flash.
    SpeakerBuilt-in 8Ω/1W *2 dual speakers
    MicrophoneSingle MIC
    SenssorsG_sensor, Geomagnetic sensor (compass), Gyro Sensor, light sensor
    Battery (Tablet)Removable Lithium-ion polymer battery 10000mAh/3.8V
    7 hours (connect to WiFi, maximum backlight brightness, RTK positioning test)
    RTC batteryBuilt-in rechargeable 3V/1mAh lithium-ion battery.
    WIFIWIFI 802.11(a/b/g/n/ac)  frequency 2.4G+5.8G dual-band WIFI
    BluetoothBluetooth BT5.2 (BLE) class1 Transmission distance: 10m
    4GGSM: B2/3/5/8
    WCDMA:B1/2/5/8
    FDD:B1/2/3/4/5/7/8/17/20/28A/28B
    TDD:B38/39/40/41
    GNSSBDS: B1I,B2I,B3I
    GPS: L1C/A,L2P(W),L5
    GLONASS: L1,L2
    Galileo: E1,E5b,E5a
    QZSS: L1,L2,L5
    Single-point positioning:2.5m
    RTK:
    Horizontal:0.8 cm + 1 ppm
    Vertical:1.5 cm + 1 ppm
    Data update rate: 1Hz/10 Hz, first cold start positioning time :30s
    I/O InterfaceStandard USB 2.0 *1, Type C *1 (Data & Charing)
    ∮3.5mm Standard earjack  *1
    SIM card  *2
    TF card *1,Max: 512GB
    12PIN Pogo Pin *1
    One out of Three
    Interface
    (3 choose 1)
    RJ45 network port *1 (10/100M adaptive) Standard
    DB9 serial port *1 (RS232)
    USB 2.0 *1
    AdapterUSB Type-C interface, supports fast charging PE+2.0, maximum power of 18W, maximum 9V/2A, European standard, CE approval
    Type-C cableType-C cable
    Rugged FeaturesMIL-STD-810H:  1.22m drop
    Working temperature: -20 °C to 60 °C
    Storage temperature: -30 °C to 70 °C
    Humidity: 95% Non-Condensing
    CertificationIP65
    CE
    CCC
    MIL-STD-810H
    FCC
    Data Collection2D Optional: Zebra SE4710
    Optical resolution:5mil
    Scanning speed:50 times/sec
    Support code system:PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse
    Maxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse
    NFC
    Support ISO/IEC 14443A/14443B/15693/18092/mifare protocol, reading distance: 0-4cm
