Rugged Vehicle Mounted Computer Fanless Industrial Panel PC Console PC Embedded Windows 10 7 System Intel J1900 4GB RAM 64GB SSD

Rugged Vehicle Mounted Computer Fanless Industrial Panel PC Console PC Embedded Windows 10 7 System Intel J1900 4GB RAM 64GB SSD  in-vehicle computer/Tablet

Product Introduction
       The All-In-One Computer Adopts An All-Aluminum Alloy Structure, Fanless And Fully Enclosed Designed, Low Power Consumption,  Compact Appearance. It is An Industrial Product Specially Designed For A Variety of Environments. It Can Ensure Long-Term Stable Work in Harsh Environment. We Pay More Attention To its Reliability, Environmental Adaptability, Real-Time Performance, Scalability, EMC Compatibility And Other Performance in The Materials of The Whole Device. The configuration Adopts Intel Celeron J1900 Quad-Core 1.99G (Maximum Core Frequency 2.4G) CPU With Windows 7  10 OS, With A High-Definition Display Interface, Multiple COM Interfaces, and USB interface, Meets Various Application Interfaces Required By The Scene, Provides A Variety of Work Efficiency, And is Widely Used in High-End Automation Fields Such As Industrial Control, Military Industry, Communication, Electricity, And Network.

Compact Appearance, Multiple Installation Methods
         The Military-Grade Aluminum Alloy Structure of The Device, High-Efficiency Heat Dissipation Design (Compatible With Fans), Ensure Stable Operation In Harsh Environments, Increase The Service Life of The Device, Safety And High Efficiency, No Noise. It Can Be Applied to High Dust, High Vibration, High Temperature, Low Temperature And Other Environments

Standard Version ( Windows 10 Home OS)

• Operation System:  Windows 10 Home   (Optional Windows 7/ 8/ Linux)
• CPU: Intel Celeron J1900 Quad-Core 1.99G (Maximum Core Frequency 2.4G)
• GPU : Integrated HD Graphic Display Core
• Display Size: 10.1"
• Display Resolution : 1280*800 Pixel IPS  Capacitive Touch  Brightness: 300cd/m2
• Memory: DDR3 1333/1600M Default 4GB  RAM
• Storage:  Hard Disk SSD Default 64GB
• Built-in : Dual Band WiFi ,Bluetooth BT4.0 (Optional 3G/4G Module  SIM, GPS Module)
• Inferface : 1*DC (GX12-3)+ 1*USB2.0 (GX12-4)+2*COM (GX12-4)+2* WiFi Antenna
• Widely Voltage Input: 12V~36V
• Overall Size:  283.7*186.2*59.9mm

Screen Parameter	Size	10.1＂
	Resolution	1280*800
	Viewing Angle	85/85/85/85 (L/R/U/D)
	Color	Chroma :16.7M
	Brightness (Standard Value)	Brightness: 300cd/m2
	Contrast	600:1
	Response Time	6.5ms
	Display Area	135.36 × 216.576 mm
	Pixel Pitch (mm)	0.1692×0.1692 (H×V)
Touch Screen	Touch Screen Type	Capacitive Touch Screen
	Resolution	500DPI
	Input Method	Handwriting or Capacitive Pen
	Surface Hardness	7H
	Calibration	Support
Hardware Configuration	CPU	Intel Celeron J1900 Quad-Core 1.99G (Maximum Core Frequency 2.4G)
	Memory	DDR3 1333/1600M Default 4GB
	Storage	Hard Disk SSD Default 64GB
	Chipset	Intel Bay Trail SOC Chipset
	Operating System	Windows 10  (Optional 7/8/Linux)
	Graphics Card	Integrated HD Graphic Display Core, Supports Dynamic Memory Allocation (DVMT)
		Support VGA, HDMI, LVDS. Built-in Dual Channel 24bit LVDS Pin Header
		Support Dual-Screen Display
	3G Module  (Optional)	PCI-E Standard Interface (Optional)
	4G Module  (Optional)	PCI-E Standard Interface (Optional)
	WiFi	Dual Band WiFi
	Bluetooth	BT4.0
	GPS        (Optional)	(Optional)
	MIC         (Optional)	(Optional)
	RTC Real Time Clock	Support
	Time Switch	Support
Interface	DC Port	1*DC 2.5
	HDMI	Supports HDMI Data Output, Up To 1080P
	USB2.0	2
	USB3.0	2
	RJ45 Ethernet	1*Realtec 8111F 1000M Default Single Network, Double Network Can Be Changed
	SD/TF	(Optional)
	Headphone	3.5mm standard interface
	SMI Card (Optional)	SIM Card Interface Standard Interface Supports Various Formats (Base on 3G/4G Module)
	RS232	2*RS232
	RS485	1(Choose One From 422)
	RS422	1(Choose One From 485)
	GPIO	/
Product Reliability	Operating Temperature	'-10 °C to 60 °C
	Storage Temperature	'-20 °C to 70 °C
	Humidity	Humidity: 95% Non-Condensing
	Mean Time Between Failures (MTBF)	7*24H
Power	Power Consumption (Maximum)	35W
	Power Consumption (Standby)
	Power Input	AC 100-240V 50/60Hz Passed CCC Certification, CE Certification
	Power Output	DC12V / 5A
